PM2260D50VRJ Crydom 快达 交流固态继电器
Crydom 快达 PM2260D50VRJ 交流固态继电器，控制电压：4-32 VDC，输出负载：48-600 VAC，50 A。随机型输出
系列简述：
PM22 系列
 |
Nova22 PM22 系列是 22.5mm 宽面板安装式固态继电器系列，可提供市场上最高功率密度，额定值高达 95 安培（600 VAC 时）。PM22s 具有接触器终端配置，包括用于控制输入的插入式连接器，提供标准螺栓或弹簧笼接线端。PM22 系列型号经过 C-UL-US 和 TUV 认证。 PM22 系列面板安装式交流 SSR 的其他功能包括：
|
同系列产品：
| 产品型号 | 控制电压范围 | 最大负载电流 | 工作电压范围 |
| PM2260A25V | 90-280 VAC/VDC | 25 A | 48-600 VAC |
| PM2260A25VH | 90-280 VAC/VDC | 25 A | 48-600 VAC |
| PM2260A25VJ | 90-280 VAC/VDC | 25 A | 48-600 VAC |
| PM2260A25VJH | 90-280 VAC/VDC | 25 A | 48-600 VAC |
| PM2260A25VR | 90-280 VAC/VDC | 25 A | 48-600 VAC |
| PM2260A25VRH | 90-280 VAC/VDC | 25 A | 48-600 VAC |
| PM2260A25VRJ | 90-280 VAC/VDC | 25 A | 48-600 VAC |
| PM2260A25VRJH | 90-280 VAC/VDC | 25 A | 48-600 VAC |
| PM2260A50V | 90-280 VAC/VDC | 50 A | 48-600 VAC |
| PM2260A50VH | 90-280 VAC/VDC | 50 A | 48-600 VAC |
| PM2260A50VJ | 90-280 VAC/VDC | 50 A | 48-600 VAC |
| PM2260A50VJH | 90-280 VAC/VDC | 50 A | 48-600 VAC |
| PM2260A50VR | 90-280 VAC/VDC | 50 A | 48-600 VAC |
| PM2260A50VRH | 90-280 VAC/VDC | 50 A | 48-600 VAC |
| PM2260A50VRJ | 90-280 VAC/VDC | 50 A | 48-600 VAC |
| PM2260A50VRJH | 90-280 VAC/VDC | 50 A | 48-600 VAC |
| PM2260A95V | 90-280 VAC/VDC | 95 A | 48-600 VAC |
| PM2260A95VH | 90-280 VAC/VDC | 95 A | 48-600 VAC |
| PM2260A95VJ | 90-280 VAC/VDC | 95 A | 48-600 VAC |
| PM2260A95VJH | 90-280 VAC/VDC | 95 A | 48-600 VAC |
| PM2260A95VR | 90-280 VAC/VDC | 95 A | 48-600 VAC |
| PM2260A95VRH | 90-280 VAC/VDC | 95 A | 48-600 VAC |
| PM2260A95VRJ | 90-280 VAC/VDC | 95 A | 48-600 VAC |
| PM2260A95VRJH | 90-280 VAC/VDC | 95 A | 48-600 VAC |
| PM2260D25V | 4-32 VDC | 25 A | 48-600 VAC |
| PM2260D25VH | 4-32 VDC | 25 A | 48-600 VAC |
| PM2260D25VJ | 4-32 VDC | 25 A | 48-600 VAC |
| PM2260D25VJH | 4-32 VDC | 25 A | 48-600 VAC |
| PM2260D25VR | 4-32 VDC | 25 A | 48-600 VAC |
| PM2260D25VRH | 4-32 VDC | 25 A | 48-600 VAC |
| PM2260D25VRJ | 4-32 VDC | 25 A | 48-600 VAC |
| PM2260D25VRJH | 4-32 VDC | 25 A | 48-600 VAC |
| PM2260D50V | 4-32 VDC | 50 A | 48-600 VAC |
| PM2260D50VH | 4-32 VDC | 50 A | 48-600 VAC |
| PM2260D50VJ | 4-32 VDC | 50 A | 48-600 VAC |
| PM2260D50VJH | 4-32 VDC | 50 A | 48-600 VAC |
| PM2260D50VR | 4-32 VDC | 50 A | 48-600 VAC |
| PM2260D50VRH | 4-32 VDC | 50 A | 48-600 VAC |
| PM2260D50VRJ | 4-32 VDC | 50 A | 48-600 VAC |
| PM2260D50VRJH | 4-32 VDC | 50 A | 48-600 VAC |
| PM2260D95V | 4-32 VDC | 95 A | 48-600 VAC |
| PM2260D95VH | 4-32 VDC | 95 A | 48-600 VAC |
| PM2260D95VJ | 4-32 VDC | 95 A | 48-600 VAC |
| PM2260D95VJH | 4-32 VDC | 95 A | 48-600 VAC |
| PM2260D95VR | 4-32 VDC | 95 A | 48-600 VAC |
| PM2260D95VRH | 4-32 VDC | 95 A | 48-600 VAC |
| PM2260D95VRJ | 4-32 VDC | 95 A | 48-600 VAC |
| PM2260D95VRJH | 4-32 VDC | 95 A | 48-600 VAC |
